Toro TransPro 200 - Installing the Wheels

SecuringtheCenterSupportto
theMainFrame
Use2screws(3/8inch)tosecurethecentersupport
tothemainframe(Figure20).
g339765
Figure20
1.Screw(3/8inch)
InstallingtheWheels
1.Mountawheelassemblytoeachaxlehubwith
4lugnuts(Figure21).
g338044
Figure21
1.Lugnut3.Axle
2.Tire
2.TorquethelugnutsasspeciedinCheckingthe
TorqueoftheWheelLugNuts(page16).
3.Deatethetirestothespecicationlistedin
CheckingtheTireAirPressure(page15).
InstallingtheRollerMountstothe
CenterSupport
Use6carriageboltsand6angenuts(5/16inch)to
securetherollermountstothecentersupport(Figure
22).
Looselyinstallthefastenerssothattherollermount
canslideback-and-forthonthecentersupport.
Tightenthefastenerstosecuretherollermounts
in-placeafteryouloadthetrailer;refertoLoadingthe
Trailer(page12).
g339764
Figure22
1.Flangenut(5/16inch)2.Carriagebolt
8
