Check Before Operating
13
m–3615
Figure 8
IMPORTANT: DO NOT HIGH–PRESSURE
WASH. High–pressure washing can damage
the electrical system or deplete grease.
5. The rear transaxle cover is an air intake area for
cooling the transaxle. Clean debris from the rear
transaxle cover before operating the tractor (Fig.
9).
1
m–3436
Figure 9
1. Rear transaxle cover
Check the Safety Interlock
System
Always check the interlock system before operating
the tractor. Instructions for checking the interlock
system are found in the Operation section, page 14.
Check the Brake
Refer to Checking and Adjusting the Brake, page 31.

Toro Wheel Horse 522xi Specifications

General

Horsepower	22 HP
Cutting Width	52 inches
Transmission	Hydrostatic
Drive	2WD
Turning Radius	18 inches
Engine	Kohler
Engine Type	4-cycle
Deck Type	Side Discharge
Cutting Height	1.5 - 4.5 inches
Speed Range	0 - 7 mph
