Maintenance
36
1256
1
2
3
Figure 47
1. Transaxle filter
2. Gasket
3. Adapter
4. Install the replacement transaxle filter to the
filter adapter. Turn the filter clockwise until the
rubber gasket contacts the filter adapter, then
tighten the filter an additional 3/4 turn (Fig. 47).
5. Fill the transaxle with the proper type of new oil;
refer to Changing/Draining Transaxle Fluid,
page 35.
Cleaning the Power Steering Filter
(Power Steering Models Only)
The power steering filter should be cleaned initially at
50 hours, then at 200–hour intervals thereafter.
Please have your Authorized Service Dealer clean the
filter.
Fuses
Service Interval/Specification
The electrical system is protected by fuses. They
require no maintenance. However, if a fuse blows,
check the component and circuit for a malfunction or
short. To replace a fuse, pull it out of the fuse box
(Fig. 48).
m–3316
4
3
2
1
Figure 48
1. F1; main–30 amp
2. F2; regulator–25 amp
3. F3; dash, interlock, and
cruise control–10 amp
4. F4; headlights and
taillights–10 amp
Headlights
Specification: Bulb # 1156 Automotive Type
Removing the Bulb
1. Disengage the power take off (PTO), set the
parking brake, lower the attachment lift, and turn
the ignition key to “STOP” to stop the engine.
Remove the ignition key.
2. Open the hood. Pull the wire connectors off both
bulb holder terminals.
