NOTE
Match "L" LABEL on LEFT
WHEELBARROW HANDLE
with "L" LABEL on REAR FRAME
NOTE
Match "R" LABEL on RIGHT
WHEELBARROW HANDLE
with "R" LABEL on REAR FRAME
2
18
17
NOTE:
Align pin in WHEEL-
BARROW HANDLE
with SLOT in RECEIVER
TUBE
11
WHEELBARROW HANDLE ATTACHMENT (OPTIONAL)
