Torque TANK M1 - Wall Mount Storage System; Wall Mount Installation

50 180
3
190150 170160
6
130 14012090 110100403010 706020 80
1 2 4 5 7
200
11
12
13
16
1-3/4"
1-3/4"
36"
6" (MIN)
FLOOR
WARNING:
The LOWER MOUNT MUST be anchored to
the wall using four WALL ANCHORS suitable
for that particular wall constuction
WARNING:
The UPPER MOUNT MUST be anchored to
the wall using four WALL ANCHORS suitable
for that particular wall construction
XTM1-WMSS
WALL MOUNT STORAGE SYSTEM (OPTIONAL)
NOTES:
The images above show the anchoring hardware used for attaching to
typical walls with wood studs spaced 16" on center. The anchors used
will depend on the wall construction. NOTE:
At least four anchoring
locations must be used in each part . The pull-out strength of the
anchoring bolts used must be greater than or equal to 200 lbs. (91 kg)
SECURELY tighten bolt connections in this step
12
