USE A PHILLIPS SCREW
DRIVER TO LOOSEN AND
REMOVE 6 SCREWS AS
SHOWN. CAREFULLY LIFT
SHROUD OFF M1.
USE A PHILLIPS SCREW DRIVER TO
LOOSEN AND REMOVE 2 SCREWS
AND CAREFULLY REMOVE HANDLE.
BOTTOM VIEW
17
SHROUD REMOVAL - STEP 1 SHROUD REMOVAL - STEP 2
