Torque TANK M1 - Table of Contents; 2010801 Washer, Steel 12.7 ID-25 Od-2 Thk Clear Zinc

50 180
3
190150 170160
6
130 14012090 110100403010 706020 80
1 2 4 5 7
200
ITEM PART NUMBER DESCRIPTION QTY
1 5661401 ASSY, CHASSIS WITH BRAKE SYSTEM 1
2 5661501 ASSY, REAR FRAME 1
3 2024401 WASHER, 8.4MM X 16MM X 1.8MM CLEAR ZINC 8
4 2009801 SCREW, M8-1.25 X 20L SOC HD GR 12.9 8
5 2010801 WASHER, STEEL 12.7 ID-25 OD-2 THK CLEAR ZINC 2
6 5654501 ASSY, REAR WHEEL 10" DIA X 3" WIDE 2
7 2010901 WASHER, LOCK M12 SAE ST ZN 2
8 2011301 SCREW, M12-1.75 X 30L SOC HD GR 12.9 CLEAR ZINC 2
9 56930PA PTD ASSY, RH PUSH HANDLE 1
10 56931PA PTD ASSY, LH PUSH HANDLE 1
11 57144PA PTD ASSY, UPPER MOUNT (OPTIONAL) 1
12 58027PA PTD ASSY, LOWER MOUNT (OPTIONAL) 1
13 2001101 WASHER, FLAT 3/8 SAE ST ZN 8
14 5617001 V-STRAP, TANK (OPTIONAL) 1
15 5560801 ASSY, TANK TOW ROPE (OPTIONAL) 1
16 2031101 SCREW, 3/8" LAG X 2.5"L CLEAR ZINC 8
17 57668PA PTD ASSY, WHEELBARROW HANDLE, LEFT (OPTIONAL) 1
18 57669PA PTD ASSY, WHEELBARROW HANDLE, RIGHT (OPTIONAL) 1
2
TABLE OF CONTENTS:
TANK M1 ASSEMBLY: PAGES 3 - 5 •
TANK M1 ADJUSTMENTS: PAGES 6 - 7 •
TANK M1 OPERATION: PAGE 8 •
OPTIONAL ATTACHMENTS: PAGE 9-11 •
TANK M1 STORAGE (OPTIONAL): PAGE 12-15 •
INSPECTION & LUBRICATION: PAGE 16 •
SHROUD REMOVAL: PAGE 17 •
CHAIN ADJUSTMENT: PAGE 18 •
SAFETY AND WARNING NOTICES: PAGE 19 •
TOOLS NEEDED FOR ASSEMBLY:
10MM ALLEN WRENCH (INCLUDED) •
6MM ALLEN WRENCH (INCLUDED) •
AIR PUMP WITH GAUGE •
PHILLIPS SCREW DRIVER •
