RIGHT UPRIGHT
LEFT UPRIGHT
RIGHT BAR SUPPORT
LEFT BAR
SUPPORT
NOTE:
INSERT BAR SUPPORTS INTO
DESIRED SLOTS ON UPRIGHTS.
PUSH DOWN TO LOCK IN PLACE
NOTE:
TO REMOVE BAR SUPPORTS FROM
UPRIGHTS, PULL SPRING PIN OUT TO
UNLOCK. LIFT UP AND PULL OUT
23
8' OLYMPIC LIFTING STATION MODULE
