LEFT UPRIGHT
RIGHT UPRIGHT
RIGHT BAR CATCH
LEFT BAR
CATCH
NOTE:
INSERT BAR CATCHES INTO
DESIRED SLOTS ON UPRIGHTS.
PUSH DOWN TO LOCK IN PLACE
NOTE:
TO REMOVE BAR CATCHES FROM
UPRIGHTS, PULL SPRING PIN OUT TO
UNLOCK. LIFT UP AND PULL OUT
8' OLYMPIC LIFTING STATION MODULE
24
