Page 10
ITM-MAGMETER-T500-ED2
1. When power supply is switched on, the instrument display shows step by step messages POWER ON and
TEST INT CL 1 to TEST INT CL 30.
2. After completing internal tests, the instrument enters to measuring mode. Basic data are immediate fl ow rate
and total volume in positive and negative fl ow directions.
Press button
to display the next page showing difference between total volumes DELTA V, total operating
hours from initial start of the instrument and value of the maximum fl ow rate 100%FLOW. Next page displays
the highest and the lowest immediate fl ow rate reached at particular measuring point.
3. Press EXE button shortly to display the last line of the datalogger. The line number is displayed in upper right
corner and its value can be max. 100. Press button
or to scroll the display by one line up or down.
Datalogger line (one screen of display) shows time data (date, hour, minute) and total volumes in particular
time.
Besides these data, it can show one of following optional values (see Chapter 8.G):
Immediate fl ow rate Q
Maximum fl ow rate reached during particular period MAX
Minimum fl ow rate reached during particular period MIN
Average fl ow rate reached during particular period AVR (Average)
Press
button shortly once again to return the instrument to basic mode. The instrument will return to basic
mode automatically if it has not been operated for approx. 60 seconds.
7. Instrument start
This manual describes confi guration of only those parameters that are useful to be changed when the instru-
ment is used in normal way.
We do not recommend changing of parameters other than mentioned here.
Detailed description of software is included in technical documentation for service engineers.
Press EXE button and hold it for approx. 3 seconds to switch the instrument from measuring mode to main
menu mode.
WARNING!
If the instrument is password protected, you will have to enter the password to open the main menu.
Message PASSWORD is displayed and the password consisting of up to 8 characters has to be ente-
red.
8. Instrument confi guration
