Page 3
ITM-MAGMETER-T500-ED2
Induction fl ow meter T-500 is designed for measuring both clean and waste water in water management
applications.
The instrument is characterized by high accuracy and stability of fl ow rate measurement in whole range of
fl ow rates from 0.1 to 10 m/s in both directions.
Measured values are displayed on a large graphical display, which is standard component of the instrument
as well as a keyboard and three programmable isolated outputs for remote transmission of measured values.
Two of them can be used as pulse or status outputs and the third one as an active current output. The stan-
dard delivery includes also an internal datalogger and RS232 communication port.
A GSM module for remote data reading via SMS text messages can be ordered as an option.
Setting of fl ow meter parameters is performed using the keyboard and intuitive display menu or using service
software via RS232 communication port.
1. General Information
2. Flow Ranges
DN m³/h DN m³/h
Qmin Qmax Qmin Qmax
15 0,065 6,48 200 11,52 1152
20 0,115 11,52 250 18 1800
25 0,18 18 300 25,2 2520
32 0,288 28,8 350 34,56 3456
40 0,45 45 400 45 4500
50 0,72 72 500 72 7200
65 1,152 115,2 600 100,8 10080
80 1,8 180 700 138,6 13860
100 2,88 288 800 180 18000
125 4,32 432 900 228,6 22860
150 6,48 648 1000 282,6 28260
