Page 11
ITM-MAGMETER-T500-ED2
Main menu options are displayed in sixteen lines.
You may select the English, Italian, Spanish and/or German language for communication. English is pre-set
as standard.
Use following keys to select an option:
scroll down by one line
scroll down by one line
move to the left by one position; it returns to the beginning of the menu in the main menu
move to the right by one position; it shifts to the end of the menu in the main menu
confi rm selection
Cursor is blinking in the position of the option selected.
A. Menu options, commands
Main menu options
RETURN Return to previous LANGUAGE Language selection (English, Ita-
lian, Spanish, German)
ANALOG
OUTPUT
Configuration of analogue output PULSE OUTPUTS Configuration of multifunctional
(pulse) outputs
COMPARATOR Selection of logical functions for
multifunctional (pulse) outputs
FREQUENCY
OUT.
Configuration of frequency output
DAMPING Instrument damping COMMUNICATION Configuration of communication
ports (RS232, GSM modem)
DATALOGGER Configuration of internal datalo-
gger
SIMULATION Flow simulation
SENSOR Downloading of sensor calibration
parameters, setting of the flow
range measured
MEASUREMENT Permit to measure the flow in
negative direction, setting of the
zero flow zone, configuration of the
empty tubing detection function
TIME Configuration of internal real-time
clock
PASSWORD Password setting
DISPLAY Selection of immediate flow rate
units and displayed decimal places
of counters
SERVICE Counter reset, check of the AD
transducer function, information on
software version
