Page 7
ITM-MAGMETER-T500-ED2
1. . Ensure that the fl ow sensor frame is connected to ground. Use the ground terminal at the outside of the
sensor for that purpose. This will prevent from undesirable interference, especially for detached versions when
shielding of the link cable between sensor and electronic unit is connected to the frame.
Remove upper cover of the instrument to get access to terminals for power cable and for signal cables.
CAUTION!
Keep on mind that induction fl ow meter is an electric device; so next steps can be performed only by
a qualifi ed person!
6. Electric connections
