Page 5
ITM-MAGMETER-T500-ED2
Nominal diameter DN 10 to DN 1200
Nominal pressure PN 10 to PN 16
Tubing connection Flanges DIN 2633
Measuring tube internal coating Rubber, PTFE
Sensing electrodes Stainless steel AISI 316L, Hasteloy
2 x measuring / 1 x indication of empty tube /1 x ground
Flow range 0,1 to 10 m/s
Measurement error 0,5% of measured value in range from 0,5 to 10 m/s
1% of measured value in range 0,1 to 0,5 m/s
Ambient temperature -20 to 60°C
Voltage 230V AC (optionally 15-24V AC/12-34V DC)
Input power 10 VA max.
Outputs 1 x programmable multifunctional (pulse, status), isolated
(relay, load 125 V ~ /1A or 30V/2A)
1 x programmable multifunctional (pulse, status), isolated
(transistor NPN, load 30 V/50 mA max.)
1 x programmable active current (0-20 mA/ 4-20 mA,
load ≤ 500Ω)
1 x RS232
Communication RS232, keyboard, permanently backlit graphical display,
SMS via internal GSM module
Datalogger Capable of recording up to 100 samples
Protection IP67: sensor / IP65: converter (compact version)
IP67/68: sensor / IP65: converter (remote version)
DN L (mm) Weight
(Kg)
15 150 2
20 150 2
25 150 2,5
32 150 3,5
40 150 5
50 200 6
65 200 9
80 200 11
100 250 13,5
125 250 20
150 300 25
200 350 35
250 400 41
300 500 55
350 500 65
400 600 110
500 600 120
