Toshiba 60th Series Service Handbook

2060, 2860/70 ADJUSTMENT 1 - 8 Dec. 1996 © TOSHIBA CORP.
Group
1
1
1
1
1
1
2
2
2
2
2
3
3
3
3
3
3
3
3
3
3
3
2
2
3
3
3
3
3
3
*1
*1 The exposure lamp stays on for 5 sec., then goes off automatically.
Code Function Code Function
1 Main motor ON 11 OFF
2 Feed roller clutch ON 12 OFF
3 Aligning roller clutch ON 13 OFF
6 Toner motor ON 16 OFF
7 Optical fan ON 17 OFF
8 Exit fan/Bottom fan ON 18 OFF
10 Total counter Increases at each “P” key press.
20 Scanning motor At 1st “P” key press, scans forward and backward at 2nd press.
21 Lens motor At 1st “P” key press, moves to 50% position and to 200% position
at 2nd press.
22 Mirror motor At 1st “P” key press, moves to 50% position and to 200% position
at 2nd press.
24 Document motor At 1st “P” key press, moves to 50% position and to 200% position
at 2nd press.
30 Charge output At 1st “P” key press, comes on and goes off at 2nd press.
31 Transfer output At 1st “P” key press, comes on and goes off at 2nd press.
32 Separation output At 1st “P” key press, comes on and goes off at 2nd press.
33 Exposure lamp At 1st “P” key press, comes on and goes off at 2nd press.
34 Pre-transfer bias At 1st “P” key press, comes on and goes off at 2nd press.
40 Copier upper cassette tray motor Tray only rises.
41 Copier upper cassette feed roller clutch At 1st “P” key press, comes on and goes off at 2nd press.
42 Copier transport clutch At 1st “P” key press, comes on and goes off at 2nd press.
43 Copier lower cassette tray motor Tray only rises.
44 Copier lower cassette feed roller clutch At 1st “P” key press, comes on and goes off at 2nd press.
45 ADU stopper end motor Reciprocates at each “P” key press.
46 ADU side end motor Reciprocates at each “P” key press.
47 ADU feed roller clutch At 1st “P” key press, comes on and goes off at 2nd press.
48 ADU stack clutch At 1st “P” key press, comes on and goes off at 2nd press.
49 PFP upper cassette tray motor Tray only rises.
50 PFP upper cassette feed roller clutch At 1st “P” key press, comes on and goes off at 2nd press.
51 PFP transport clutch At 1st “P” key press, comes on and goes off at 2nd press.
52 PFP middle cassette tray motor Tray only rises.
53 PFP middle cassette feed roller clutch At 1st “P” key press, comes on and goes off at 2nd press.
1.2.2 Output signal check (03/04)
In the “03” or “04” test mode, the following output signal conditions can be checked by entering appro-
priate codes.
