2060, 2860/70 ADJUSTMENT 1 - 38 Dec. 1996 © TOSHIBA CORP.
1.8.4 Image inclination
Paper
Direction of the copy paper
movement
Direction of the copy paper
movement
If inclination of the image occurs even though the
edge of the original is properly aligned with the
scale, adjust by moving the original scale.
In case of
AA
AA
A
• Move the original scale in the direction indicated
by
In case of
BB
BB
B
• Move the original scale in the direction indicated
by
A
B
AB
