Toshiba B-SA4TM SERIES - Appearance; Dimensions; Front View; Rear View

1. PRODUCT OVERVIEW ENGLISH VERSION EO1-33047
1.4 Appearance
E1- 3
1.4 Appearance
1.4.1 Dimensions
1.4.2 Front View
1.4.3 Rear View
The names of the parts or units introduced in this section are used in the
following chapters.
Dimensions in mm (inches)
LCD Message
Display
Operation Panel
Media Outlet
Top Cover
Front Cover
Supply Window
Top Cover
Release Button
RS-232C Serial
Interface Connector
(Option)
Ribbon Cover
USB Interface
Connector
Parallel Interface
Connector
(Centronics)
AC Power Inlet
LAN Interface
Connector
Power Switch
O: OFF
I: ON
238 (9.4)
331.5
(13.1)
401.7 (15.8)
Wireless LAN
Interface Board
(Option)
Expansion I/O Interface
Connector (Option)
