CODE No. list (Example)
*1 The initial setup value of EEPROM installed on the service P.C. board
CODE No. (DN) Item Setting data Factory-set value
01
Filter sign lighting time Depending on Type
02
Filter pollution leve 0000: standard
03
Central control address 0099: Not determined
06
Heating suction temperature shift 0002: + 3.6°F(+ 2°C)
0F
Cooling only 0000: Heat pump
10
Type Depending on model type
11
Indoor unit capacity Depending on capacity type
12
System address 0099: Not determined
13
Indoor unit address 0099: Not determined
14
Group address 0099: Not determined
19
Louver type (wind direction adjustment) Depending on Type.
28
Power failure automatic recovery 0000: None
32
Sensor SW (Selection of static pressure) 0000: Body sensor
5d
High ceiling select 0000: Standard
60
Timer setting (wired remote controller) 0000: Available
F0
Swing mode 0001: Standard
F1
Louver fixing position (Flap No. 1) 0000: Not fixed (4-way type only)
F2
Louver fixing position (Flap No. 2) 0000: Not fixed (4-way type only)
F3
Louver fixing position (Flap No. 3) 0000: Not fixed (4-way type only)
F4
Louver fixing position (Flap No. 4) 0000: Not fixed (4
-way type only)
Type
Code No. [10]
Setup data Type Model abb. name
0001 *1 4-way Air Discharge Cassette MMU-AP
2H2UL
0007 Ceiling MMC-AP
1H2UL
0008 High Wall MMK-AP
3H2UL
0014 Compact 4-way Cassette
MMU-AP
***
1MH2UL
Indoor unit capacity
CODE No. [11]
Setup data Model Setup data Model
0000* Invalid 0016
0001 007 type 0017 048 type
042 type
0002 — 0018 056 type
0003 009 type 0019 —
0004 — 0020 —
0005 012 type 0021 072 type
0006 — 0022 —
0007 015 type 0023 096 type
0008 — 0024 —
0009 018 type
021 type
0025 —
0010 0026 —
0011 024 type 0027 —
0012 027 type 0028 —
0013 030 type ~ —
0014 — 0034 —
0015
036 type
Tabel 1
***
***
***
