tenna connections
tf you are using an antenna system, follow these instructions, _fyou are a CabmeTV subscr}ber, sk}p ahead
to page 18 for the proper connections,
IANTENNA TO DVD/VCR CONNECTION I
The DVD/VCR must be connected "between" the antenna and the TV. First, disconnect the antenna from the TV
and connect it to the DVD/VCR. Then connect the DVD/VCR to the TV. Below are 3 common methods of connect-
ing an antenna system to a DVD/VCR. Find the type of antenna system you are using and follow the connection
diagram.
Combination UHF/VHF antenna with 75 ohm coa×iaJ cable
DVD/VC R
_mm.mmm.
75 ohm coaxial cable
÷
f
Combination UHF/VHF antenna with 300 ohm twin tead (fiat) wire
Matching transformer
300 ohm input [_
75 ohm output
'
(not supplied_
DVD/VCR
÷
|m %
"t 300 ohm twin lead (flat) wire
Separate UHF and VHF antennas
__VHF_ Combiner
75/300 ohm input
75 ohm output
_ (not supplied)
.. . 300 ohm twin lead (flat) wire
.
I
)-
._...... _ 0. _,
L
75 ohm coaxial cable
DVD/VCR
NOTE: If both UHF and VHF antennas have 300 ohm twin lead (flat) wires,
use a combiner having two 300 ohm inputs and one 75 ohm output.
NOTES:, A clear picture wiII not be obtained by the DVD/VCR unless the antenna signal is good. Connect the
antenna to the DVD/VCR properly.
, For better quaIity recording, an indoor antenna or a telescopic antenna is not recommended. The use
of an outdoor type antenna is required.
, If you are not sure about the connection, please refer to quaIified service personnel.
