IPT1020-SD Settings
Setting the IPT1020-SD Headset Transmit Volume
96 Strata CTX DKT/IPT Telephone 06/03
Setting the IPT1020-SD Headset Transmit
Volume
1. Press ++++ROG (simultaneously).
2. Press
.
3. Press the Feature Buttons to turn the LEDs On/Off for the desired volume
transmission level (see Table 15).
4. Press FB4 for handset voice output in speakerphone mode (LED On = with, LED
Off = without).
5. Press
+ROG to set the above data.
6. Go off-hook and hang up.
Viewing IPT1020-SD Terminal Information
1. Press ++++ROG (simultaneously).
2. Press
, then press +ROG.
3. Press
)% to view IPT firmware version (application and boot versions, read
only).
4. Press
)% to view IPT MAC address (read only).
5. Go off-hook and hang up.
Table 15 Volume Level Transmitted from Headset Microphone
LEDS
Transmit Level
FB3 FB2 FB1
ON ON ON Level 7 (min.)
ON ON OFF Level 6
ON OFF ON Level 5
ON OFF OFF Level 4
OFF ON ON Level 3 (initial value)
OFF ON OFF Level 2
OFF OFF ON Level 1
OFF OFF OFF Level 0 (max.)
To Next Page
