4 SCAN FUNCTIONS
Setting Up Scan Options 89
Setting Up Scan Options
You can make various options to affect the scanning status. You can save different sets of options in files and recall one of
them for frequent use.
 Scan options
The basic and advanced dialogs are available for the scan operation.
 Basic scan dialog
When you execute the image acquisition command, the following basic scan dialog appears.
1) Easy Set
The scan options can be saved.
 P.91 “Using the Easy Set feature”
2)
Clears the preview image.
3) Preview screen
The pre-scanned image appears. The dotted boundary shows the scanning area or the original size. The image
information appears under the preview screen.
4)
Shows the version information of the scanner driver.
5)
Shows the Help information about this scanner driver.
6) [Close]
Quits the scanning operation.
7) [Pre-Scan]
Pre-scans the original.
8) [Scan]
Scans the original.
9) Measurement unit
Select [Inch], [mm], or [Pixel] to change the measurement unit.
10)
Opens the advanced scan dialog.
 P.90 “Advanced scan dialog”
1
2
4
5
6 7 8
3
9
10

Toshiba e-studio 2006 Specifications

General

Functions	Print, Copy, Scan, Fax
Print Technology	Laser
Print Speed	20 ppm
Print Resolution	2400 x 600 dpi
Copy Speed	20 cpm
Copy Resolution	600 x 600 dpi
Scan Resolution	600 x 600 dpi
Fax Transmission Speed	33.6 kbps
Paper Capacity	250 sheets
Monthly Duty Cycle	15, 000 pages
Zoom	25-400%
Maximum Paper Size	A3
Duplex Printing	Manual
Dimensions	575 x 540 x 402 mm
Type	All in One Printer
Connectivity	USB, Ethernet
Paper Size	A3, A4, A5
Operating System Compatibility	Windows, Mac
