1 TROUBLESHOOTING FOR THE HARDWARE
22 Clearing a Paper Misfeed
Paper misfeed in the bypass tray
2
Pull out the right-hand tray and remove the misfed
paper.
3
Check that there is no folded/curled paper or
overloading, and then close the drawer of the Large
Capacity Feeder.
Be sure that the height of the stacked paper does not
exceed the line indicated inside of the side guides.
2
1
1
Move the green paper holding lever toward the
outside.
The paper can now be removed.
2
Pull out the misfed paper in the bypass tray.
3
Place paper in the bypass tray again and then move
the green paper holding lever toward the inside.
If a sheet of paper is stained, folded or torn, replace it with a
new one.
1
2
To Next Page
