1 TROUBLESHOOTING FOR THE HARDWARE
24 Clearing a Paper Misfeed
Paper misfeed on the paper transport path
Be careful not to let your fingers be caught between the equipment and the duplexing unit cover or
automatic duplexing unit cover.
This could injure you.
3
Close the automatic duplexing unit cover.
Paper misfeed in the fuser unit
y Be careful not to let your fingers be caught between the equipment and the duplexing unit cover or
automatic duplexing unit cover.
This could injure you.
y Do not touch the fuser unit or the metal portion around it.
Since they are very hot, you could be burned or the shock could cause you to get your hand injured in the
machine.
1
Open the automatic duplexing unit cover on the right.
2
Remove the misfed paper.
y Be sure not to touch the transfer belt when removing the
misfed paper. This could stain copy images.
y Do not clean roller [A] though it may be stained. It will be
automatically cleaned at the next printing.
To Next Page
