Selecting Finishing Modes 125
Hole punch mode (optional)
When the Hole Punch Unit (optional) is installed to the finisher (optional), you can punch holes in
the copies.
y The available copy paper sizes for this mode are A3, A4, A4-R, B4, B5, B5-R and FOLIO.
y The paper weight applicable for this mode is 64 g/m
2
to 256 g/m
2
.
Special paper such as OHP films or sticker label cannot be used for hole punching.
1
Place paper in the drawer(s).
When using this mode in bypass copying, specify the paper size in advance. ( P.85
“Bypass Copying”)
2
Place the original(s).
3
Press the finisher button on the basic menu.
4
Press the [HOLE PUNCH] button.
Set other copy modes as required.
5
Press the [START] button.
To Next Page
