SETTING / ADJUSTMENT
6 - 24
6.4.2 Density adjustment
The center density and the density variation controlled by density adjustment keys can be adjusted as
follows.
< Adjustment Mode (05) >
Make a test copy and compare the image obtained with the current settings; if necessary, make
adjustment using the following procedure.
<Procedure>
(1) While pressing [0] and [5] simultaneously, turn the power ON.
(2) Key in a code and press the [START] button.
(3) Key in an adjustment value.
(To correct the keyed-in value, press the [CLEAR/STOP] button.)
(4) Press the [OK] button to store the value.  The equipment goes back to the test mode A screen.
(5) Press the [SETTINGS] button and then the [START] button. Then perform test copying.
(6) If the desired image density has not been attained, repeat step (1) to (5).
Original mode
BackGround
Erase
Item to be
adjusted
Remarks
Text/Photo Photo Text
7114 7116 7115 7143 Manual
density mode
center value
The larger the value is, the darker the
image becomes.
Acceptable values: 0 to 255
(Default: 128)
7123 7125 7124 7142 Automatic
density mode
The larger the value is, the darker the
image becomes.
Acceptable values: 0 to 255
(Default: 128)
