5
© 2008 - 2011 TOSHIBA TEC CORPORATION All rights reserved e-STUDIO2020C/2330C/2820C/2830C/3520C/3530C/4520C
PREVENTIVE MAINTENANCE (PM)
5 - 41
5.8 PM KIT
A PM kit is a package for each unit of replacement parts requiring PM.
KIT name Component Part name Qty.
DEV-KIT-FC28K-N Drum cleaning blade BL-FC28D 1
Main charger grid GRID-CHARGR-MAIN-F45X 1
Needle electrode ELCTRD-CHARGR-MAIN-380 1
Main charger cleaner FILM-CLNR-GRID-F45X 2
Developer material D-FC28-K 1
Developer unit filter
ASYS-DUCT-DEV-COV
1
Ozone filter 1 FLTR-OZON-45X-CBO-600M 1
Slit glass cleaner pad ASYS-CLNR-GLASS 1
DEV-KIT-FC28CLR-N Drum cleaning blade BL-FC28D 3
Main charger grid GRID-CHARGR-MAIN-F45X 3
Needle electrode ELCTRD-CHARGR-MAIN-380 3
Main charger cleaner FILM-CLNR-GRID-F45X 6
Developer material (Y) D-FC28-Y 1
Developer material (M) D-FC28-M 1
Developer material (C) D-FC28-C 1
Developer filter ASYS-DUCT-DEV-COV 3
TBU-KIT-FC28 Transfer belt cleaning blade BL-FC35TR 1
2nd transfer roller CR-FC35TR2 1
Blade seal (front side) SEAL-BLADE-CLN-TBU-F 1
Blade-seal (rear side) SEAL-BLADE-CLN-TBU-R 1
2nd transfer facing roller
cleaning Mylar
MYLAR-CLN-TR2-WP-450 1
Ozone filter 2 FLTR-OZ-50-TNR-EX-450 1
FR-KIT-FC28 Fuser belt BT-FC35-FU 1
Fuser roller FR-FC28-U 1
Press roller HR-FC28-L 1
Separation finger SCRAPR-FUS-350 5
Fuser belt guide COLLAR-HR-T1 2
PM-KIT-ROLLER Pick up roller ROLLER-PICK-AT 1
Feed roller K-ROLL-FEED 1
Separation roller ASYS-ROLL-SPT 1
ROL-KIT-1010 Pick up roller ROL-PICK-UP 1
Feed roller ROL-PAPER-FED-F 1
Separation roller ROL-PAPER-FED-S 1
DF-KIT-3018 Pick up roller ASYS-ROL-FEED 1
Feed roller ASYS-ROL-FEED 1
Separation roller ASYS-ROL-RET 1
To Next Page
