Toshiba MD13M1 Service Manual

C-2
WHEN REPLACING EEPROM (MEMORY) IC
If a service repair is undertaken where it has been required to change the MEMORY IC, the following steps should be taken to
ensure correct data settings while making reference to TABLE 1.
Table 1
1.
2.
3.
4.
5.
6.
7.
8.
The unit will now have the correct DATA for the new MEMORY IC.
Enter DATA SET mode by setting VOLUME to minimum.
Press both VOL. DOWN button on the set and Channel button (6) on the remote control for more than 1 second.
ADDRESS and DATA should appear as FIG 1.
ADDRESS is now selected and should "blink". Using the VOL. UP/DOWN button on the remote, step through the
ADDRESS until required ADDRESS to be changed is reached.
Press ENTER to select DATA. When DATA is selected, it will "blink".
Again, step through the DATA using VOL. UP/DOWN button until required DATA value has been selected.
Pressing ENTER will take you back to ADDRESS for further selection if necessary.
Repeat steps 3 to 6 until all data has been checked.
When satisfied correct DATA has been entered, turn POWER off (return to STANDBY MODE) to finish DATA input.
Note: No need setting for the position of the mark @ due to the adjustment value.
FA 43 0F 05 F1 B7 27 D7 03 CD
+0 +1 +2 +3 +4 +5 +6 +7 +8 +9 +A +B +C +D +E +F
INI
64 67 69 2A 6B 6C 6D 6E 6F10 26 70 71 52 72 53 73
00 DA BF BF C0 60 62
54 55 75 75 56 56 76 76 5720 74 57 77 77 58 58 78
78 59 79 79 5A 5A 7A 7A 5B30 59 5B 7B 7B 5C 5C 7C
7C 5D 7D 7D 5E 5E 7E 7E 5F40 5D 5F 5F 7F 7F @ @
@ @@@@@@@@50 @ @ @ @ @ @ @
@ @@@@@@@@60 @ @ 10 76 53 0A 55
82 --- --- --- --- --- --- --- ---70 --- --- --- --- --- --- ---
CONFIRMATION OF HOURS USED
POWER ON total hours can be checked on the screen. Total hours are displayed in 16 system of notation.
NOTE: If you set a factory initialization, the total hours is reset to "0".
1.
2.
3.
Set the VOLUME to minimum.
Press both VOL. DOWN button on the set and Channel
button (6) on the remote control for more than 1 second.
After the confirmation of using hours, turn off the power.
ADDRESS DATA
INIT 00 FA
CRT ON 0010
Initial setting content of MEMORY IC.
POWER ON total hours.
= (16 x 16 x 16 x thousands digit value)
+ (16 x 16 x hundreds digit value)
+ (16 x tens digit value)
+ (ones digit value)
FIG. 1
