1.
2.
Remove the Back Cabinet and Power PCB/DVD Block.
(Refer to item 1 of the DISASSEMBLY
INSTRUCTIONS.)
Rotate the black gear of Deck CD section in the direction of the arrow by hand, remove the disc from
Deck CD.
(Refer to Fig. 1)
DISC REMOV
AL METHOD
A
T NO POWER SUPPL
Y
Fig. 1
Deck CD
Gear (Black)
A1-4
4
6
Table of Contents
Default Chapter
2
Caution
2
Important Safeguards
3
Disc Removal Method at no Power Supply
5
Table of Contents
6
General Specifications
7
1 Removal of Mechanical Parts and P.C. Boards
13
Disassembly Instructions
13
2 Removal of Anode Cap
15
Removal and Installation of Flat Package IC
16
Service Mode List
18
Confirmation of Using Hours
19
When Replacing Eeprom(Memory) IC
19
Power
20
Tv
20
Electrical Adjustments
20
DVD
20
Deflection
25
Stereo
25
Crt
25
Av Sw
25
Mechanical Replacement Parts List
28
Electrical Replacement Parts List
29
