User’s Manual EN-43
dynadock™
Specifications
This section summarizes the dynadock’s technical specifications.
Physical Dimensions
Environmental Requirements
Power Requirements
Weight About 490g/17.2 ounces (including the Base)
Size 42 (w) x 77 (d) x 222 (h) mm/1.7" (w) x 3.0" (d) x 8.7" (h)
(not including the parts that extend beyond the main
body)
112.5 (w) x 130 (d) x 234 (h) mm/4.4" (w) x 5.2" (d) x 9.3"
(h) (including the Base)
Conditions Ambient temperature Relative humidity
Operating 5°C to 35°C (41°F to 95°F) 20% to 80%
Non-operating -20°C to 65°C (-4°F to 149°F) 10% to 90%
Thermal Gradient 20°C per hour maximum
Wet-bulb Temperature 26°C maximum
AC adaptor 100-240 volts AC
50-60 hertz (cycles per second)
15V DC
3.0/4.0 amperes (different for each model)
