User’s Manual 4-9
Qosmio F60 Series
Loading discs
To load a disc, follow the steps as detailed below:
1. When the computer’s power is on, press the eject button to open the
disc tray slightly. Grasp the disc tray gently and pull until it is fully
opened.
Figure 4-3 Pressing the eject button and pulling the disc tray open
2. Lay the disc, label side up, in the disc tray.
Figure 4-4 Inserting a disc
1. Eject button
2. Disc tray
1. Laser lens (Super Multi Drive model)
1. Laser lens (BD Drive model)
1
2
1
1
