FILE NO. SVM-05027
– 82 –
1) Turn the power supply off to stop the operation
of air conditioner.
2) Remove the front panel.
• Remove the 4 fixing screws.
3) Remove the electrical part base.
1 Common
procedure
11-2. Microcomputer
Replace the thermal fuse, terminal
block, microcomputer ass’y and the
P.C. board ass’y
<P.C. board layout> (For 13NKV)
No. Part name Procedures Remarks
Top View
To Next Page
