– 81 –
No. Part name Procedure Remarks
9 Fan motor, Multi
blade fan
NOTE)
Arrange the multi blade fan so that screws
position at the right side against the drain pan.
NOTE)
Fix multi blade fan with torque wrench 4.9 N•m or
more.
3) Perform the procedure in steps 2-3) and 2-4)
of “8Fan case (lower/upper)” to attach the fan
case (lower).
4) Reconnect the cables that you disconnected in
steps 1-3) and 1-4) of “9Fan motor, Multi
blade fan”.
NOTE)
Check there is no missing or poor contact of the
connectors.
Finally check whether the multi blade fan turns
surely and smoothly or not.
To Next Page
