Toshiba RD-XV48DTKB Service Manual

20080529 1-21-1 E3NG1EL
ELECTRICAL PARTS LIST
PRODUCT SAFETY NOTE: Products marked with a
! have special characteristics important to safety.
Before replacing any of these components, read
carefully the product safety notice in this service
manual. Don't degrade the safety of the product
through improper servicing.
NOTES:
1. Parts that are not assigned part numbers (---------)
are not available.
2. Tolerance of Capacitors and Resistors are noted
with the following symbols.
DVD MECHANISM & DVD/HDD MAIN
BOARD ASSEMBLY
AV ASSEMBLY
BOARD AV
BOARD POWER SWITCH
BOARD SENSOR
BOARD DTV MODULE UNIT
PW/SW ASSEMBLY
BOARD POWER SUPPLY
BOARD FRONT JACK
C.....±0.25% D.....±0.5% F.....±1%
G.....±2% J......±5% K.....±10%
M.....±20% N.....±30% Z.....+80/-20%
!
Location
No.
TSB P/N Reference No. Description
! P2 79104039 N78EBEBN DVD MECHANISM & DVD/HDD
MAIN BOARD ASSEMBLY
!
Location
No.
TSB P/N Reference No. Description
! P1 79104036 (Not Available) AV ASSEMBLY
Consists of the following
P4
P6
----------
----------
79103349
79104038
----------
----------
----------
1VSA13519
1VSA18504
----------
BOARD AV
BOARD POWER SWITCH
BOARD SENSOR
BOARD DTV MODULE UNIT
BOARD REAR JACK
!
Location
No.
TSB P/N Reference No. Description
---------- ---------- BOARD AV
Following parts are included in BOARD AV.
SW521 79102423 SST0101AL041 TACT SWITCH SKQSAF001A
SW522 79102423 SST0101AL041 TACT SWITCH SKQSAF001A
SW523 79102423 SST0101AL041 TACT SWITCH SKQSAF001A
SW524 79102423 SST0101AL041 TACT SWITCH SKQSAF001A
SW525 79102423 SST0101AL041 TACT SWITCH SKQSAF001A
SW1501 79102423 SST0101AL041 TACT SWITCH SKQSAF001A
SW1502 79102423 SST0101AL041 TACT SWITCH SKQSAF001A
! TU1800 79104042 UTUNDVTMS003 TUNER UNIT ENGF7709KF
W3 79103723 WX1E3N00-003 WIRE ASSEMBLY 30PIN FFC
WX1E3N00-003
W8 79103725 WX1E3N00-006 WIRE ASSEMBLY 6PIN FFC
WX1E3N00-006
!
Location
No.
TSB P/N Reference No. Description
---------- ---------- BOARD POWER SWITCH
Following part is included in BOARD POWER SWITCH.
SW1601 79102423 SST0101AL041 TACT SWITCH SKQSAF001A
!
Location
No.
TSB P/N Reference No. Description
P4 79103349 1VSA13519 BOARD SENSOR
!
Location
No.
TSB P/N Reference No. Description
P6 79104038 1VSA18504 BOARD DTV MODULE UNIT
!
Location
No.
TSB P/N Reference No. Description
! P3 79104037 (Not Available) PW/SW ASSEMBLY
Consists of the following
----------
----------
----------
----------
----------
----------
BOARD POWER SUPPLY
BOARD FRONT JACK
BOARD SWITCH
!
Location
No.
TSB P/N Reference No. Description
---------- ---------- BOARD POWER SUPPLY
Following parts are included in BOARD POWER SUPPLY.
! C1001 79102416 CT2E683DC016 ACROSS THE LINE CAP.
0.068μF/250V
! C1006 79103607 CCN2EMA0E222 SAFTY CAP. 2200PF/250V
! IC1001 79102400 QPEWPS2561A1 PHOTOCOUPLER PS2561A-
1(W)
! L1003 79103713 LLEG0Z0Y2027 COIL LINE FILTER ST0710ET24-
013
! Q1001 79103611 QFWZ2SK3798Q MOS FET 2SK3798(Q)
! R1001 79103612 RXX2565MGL01 GLASS GLAZE RES. 1/2W J
5.6M Ω
! AC1001 79103616 WAB0182LW020 POWER CORD W/O A GND
WIRE BS / 1860MM / BLACK
! F1001 79103718 PDGJBB0NG252 FUSE TIME RAG FIH 250V 2.5A
! SA1001 79102397 NVQZ10D471KB SURGE ABSORBER 470V+-
10PER
! T1001 79103714 LTT3PE0KT042 TRANS POWER 8710
W1 79103721 WX1E3N00-001 WIRE ASSEMBLY 34PIN FFC
WX1E3N00-001
W4 79103724 WX1E3N00-004 WIRE ASSEMBLY 30PIN FFC
WX1E3N00-004
W7 79103726 WX1E3N00-007 WIRE ASSEMBLY 20PIN FFC
WX1E3N00-007
!
Location
No.
TSB P/N Reference No. Description
---------- ---------- BOARD FRONT JACK
Following parts are included in BOARD FRONT JACK.
SW3002 79102423 SST0101AL041 TACT SWITCH SKQSAF001A
SW3003 79102423 SST0101AL041 TACT SWITCH SKQSAF001A
SW3004 79102423 SST0101AL041 TACT SWITCH SKQSAF001A
SW3005 79102423 SST0101AL041 TACT SWITCH SKQSAF001A
SW3006 79102423 SST0101AL041 TACT SWITCH SKQSAF001A
SW3007 79102423 SST0101AL041 TACT SWITCH SKQSAF001A
