CABINET DISASSEMBLY INSTRUCTIONS
1. Disassembly Flowchart
This flowchart indicates the disassembly steps to gain
access to item(s) to be serviced. When reassembling,
follow the steps in reverse order. Bend, route, and
dress the cables as they were originally.
2. Disassembly Method
Note:
(1): Identification (location) No. of parts in the figures
(2): Name of the part
(3): Figure Number for reference
(4): Identification of parts to be removed, unhooked,
unlocked, released, unplugged, unclamped, or
desoldered.
P=Spring, L=Locking Tab, S=Screw,
CN=Connector
*=Unhook, Unlock, Release, Unplug, or Desolder
e.g. 6(S-1) = six Screws (S-1),
5(L-1) = five Locking Tabs (L-1)
(5): Refer to “Reference Notes.”
NOTE: BOARD MEANS PRINTED CIRCUIT BOARD.
ID/
LOC.
No.
PART
REMOVAL
Fig.
No.
REMOVE/*UNHOOK/
UNLOCK/RELEASE/
UNPLUG/DESOLDER
Note
[1] Cover Top D1 7(S-1) ---
[2]
Front
Assembly
D2 (S-2), *5(L-1), *3(L-2) 1
[3]
Front
Bracket
D2
(S-3), 3(S-4), Front
Support
---
[4]
HDD
Assembly
D3
(S-5), 3(S-6), *CN652,
Connector
---
[5]
DVD
Mechanism
& DVD/
HDD MAIN
BOARD
Assembly
D3
(S-7), 2(S-8), 2(S-9),
2(S-10), *CN101,
*CN502-D, *CN701,
*CN901, Dust Cover,
Hook, Mecha Plate
Earth
2
[6]
HDD
Bracket
D4 4(S-12) ---
[7] HDD Unit D4 4(S-13), HDD Rubber 2
[8]
HDD
Support
D4 ---------- ---
[9]
BOARD
ATA
D4 *CN3001, *CN3002 ---
[1] Cover Top
[2] Front
Assembly
[3] Front
Bracket
[22] Front
Bracket R
[23] Bracket R
[4] HDD
Assembly
[7] HDD Unit
[8] HDD
Support
[6] HDD
Bracket
[15] BOARD
Front Jack
[5] DVD Mechanism
& DVD/HDD MAIN
BOARD Assembly
[13] BOARD
Power
Supply
[14] BOARD
Switch
[10] Fan Holder
[11] Motor DC
Fan
[12] Panel Rear
[17] Deck
Assembly
[21] Deck
Pedestal
[16] VCR
Chassis Unit
[20] BOARD
Power
Switch
[18] BOARD
AV
[19] BOARD
DTV Module Unit
[9] BOARD ATA
[10] Fan Holder D5 2(S-14), *CN1002 ---
[11]
Motor DC
Fan
D5 2(S-15) ---
[12] Panel Rear D5 (S-16), 3(S-17) ---
[13]
BOARD
Power
Supply
D6
(S-18), 3(S-19),
(S-20), *CN1503, FFC
Guide, Chassis Earth
Plate
---
[14]
BOARD
Switch
D6 (S-21), Desolder ---
[15]
BOARD
Front Jack
D6 2(S-22), *CN3011 ---
[16]
VCR
Chassis
Unit
D7
5(S-23), 4(S-24),
(S-25)
---
[17]
Deck
Assembly
D8
(S-26), (S-27),
Desolder
3
4
[18] BOARD AV D8 ---------- ---
[19]
BOARD
DTV
Module
Unit
D8 Desolder ---
[20]
BOARD
Power
Switch
D8 Desolder ---
[21]
Deck
Pedestal
D9 7(S-28) ---
[22]
Front
Bracket R
D9
(S-29), 2(S-30), DV
Cable, DV Plate Earth
---
[23] Bracket R D9 2(S-31) ---
↓
(1)
↓
(2)
↓
(3)
↓
(4)
↓
(5)
ID/
LOC.
No.
PART
REMOVAL
Fig.
No.
REMOVE/*UNHOOK/
UNLOCK/RELEASE/
UNPLUG/DESOLDER
Note
