Toshiba RD-XV48DTKB Service Manual

WAVEFORMS
1-15-1
TD5PWF
WF9
AUDIO(L)-OUT
Pin 17 of CN1502
1V 0.5ms
WF7
VIDEO-Cb
Pin 3 of CN1502
0.2V 20 μ s
WF8
VIDEO-Cr
Pin 5 of CN1502
0.2V 20 μ s
SPDIF 1V 0.1 μ s
WF10 Pin 28 of CN1503
WF4 Pin 7 of CN1502
VIDEO-Y 0.2V 20 μ s
WF5 Pin 9 of CN1502
VIDEO-C 0.2V 20 μ s
WF6 Pin 30 of IC1509
VIDEO-CVBS 0.5V 20 μ s
NOTE:
Input: COLOR BAR SIGNAL (WITH 1KHz AUDIO SIGNAL)
WF3
WF1
UPPER
WF2
WF2
LOWER
TP504
UPPER
LOWER
TP504
TP301
V-OUT 0.5V
50
μs RF-SW 5V
C-PB
RF-SW 5V 5m
s
0.2V
WF1
Pin 56 of IC301
V-OUT E-E 0.2V 20 μs
Pin 56 of IC301
