MAINTENANCE
Service Schedule of Components
This maintenance chart shows you the standard of replacement and cleaning time for each part.
Because those may replace depending on environment and purpose for use, use the chart for reference.
Notes:
1.Clean all parts for the tape transport (Upper Drum with Video Head / Pinch Roller / ACE Head / FE Head)
using 90% ethyl alcohol.
2.After cleaning the parts, do all DECK ADJUSTMENTS.
3.For the reference numbers listed above, refer to Deck Exploded Views.
h: Hours : Cleaning : Replace
Deck Periodic Service Schedule
Ref.No. Part Name 1,000 h 2,000 h 3,000 h 4,000 h
B2
Cylinder Assembly
B3
Loading Motor Assembly
B8
Pulley Assembly
B587 Tension Lever Assembly
B31
ACE Head Assembly
B573, B574
Reel S, Reel T
B37 Capstan Motor
B52
Cap Belt
B73 FE Head
B86 F Brake Assembly (HI)
B133
Idler Assembly (HI)
B410 Pinch Arm Assembly
B414
M Brake (SP) Assembly (HI)
B416
M Brake (TU) Assembly (HI)
B525 LDG Belt
