2-2-1 E9NG0PFIX
SERVICE FIXTURE AND TOOLS
J-1-1, J-1-2 J-2
J-3 J-4
J-5
Ref. No. Name Part No. Adjustment
J-1-1 Alignment Tape FL6A Head Adjustment of ACE Head
J-1-2 Alignment Tape FL6N8
(2 Head model)
FL6NS8
(4 Head model)
Azimuth and X Value Adjustment of ACE Head /
Adjustment of Envelope Waveform
J-2 Guide Roller Adj. Screwdriver Available
Locally
Guide Roller
J-3 Mirror Available
Locally
Tape Transportation Check
J-4 Azimuth Adj. Screwdriver + Available
Locally
ACE Head Height
J-5 Flat Screwdriver - Available
Locally
X Value
To Next Page
