3 Tests and Diagnostics 3.16 Expansion Test
Satellite A50S/TECRA A3X Maintenance Manual (960-534) [CONFIDENTIAL] 3-33
Subtest 02 RGB monitor ID
NOTE: To execute this subtest, RGB monitor ID wraparound connector is required.
The wiring diagram of the connector is described in Appendix F.
Connect a wraparound connector to CRT monitor for the test of ID acquisition.
This subtest is executed by using VESA command.
