Changing a Function’s Set Value
From the instructions above, after pressing the [READ/ENTER] key the display will show the value of that
function with one digit flashing (usually the rightmost digit). Flashing indicates this is the digit to be altered
(similar to cursor position). Use the UP arrow key to increment the value of the flashing digit. Use the DOWN
arrow key to decrement the value of the flashing digit. Use the LEFT or RIGHT arrow to select the next digit to
be altered. Values can only be changed within the Adjustment Range of the function parameter.
Pressing the [READ/ENTER] key again will store the new programming for that Function and return to the
Function display.
If the display shows [Inh] when trying to store the changes, the unit is running and must be Stopped, or a
Password has been set up to prevent access and must be entered first. See section 5.6.11 of the Advanced
Installation, Operation and Programming Manual for details about this feature.
Caution!
If the Fn key is pressed or power is lost before the [READ/ENTER] key is pressed, the TE
Series Starter will not store the selected value in memory.
Fault Mode
The Fault Mode Display provides information to the operator when a fault occurs and allows the operator to
review fault history. Refer to described in Section 7 of the Advanced Installation, Operation and Programming
Manual for details. Fault codes are displayed by 3 alpha characters. The first and second characters (reading
left to right) are the initials for the applicable English-language fault name. The third or right-most character
can be either A, c, or d to denote when the fault occurred: “A” denotes Acceleration, “c” denotes Constant
speed, and “d” denotes Decel or Stopped.
