Auxiliary Output Relay Settings
Functions F060 through F062 provide the ability to program the functions of each of the 3 Output
Auxiliary Relays. Factory default programming is provided which covers a wide variety of applications,
but any of these relays can be changed as per the following chart.
Notes:
Check relay wiring before changing programming to avoid unintended consequences.
Relays programmed to some protection features will not operate if function is disabled
elsewhere.

Setting
Relay Operation Description
Setting
Relay Operation Description
1 Run / Stop (Changes on Start, resets on Stop) 14 Ground Fault Trip
2 At-Speed / Stop 15 Phase Rotation Trip
3 At-Speed / End of Decel 16 Any Trip (#5 - #15)
4 Start / End of Decel 17
Any Trip, (#5-#15) flashing output*
5 Short SCR Trip 18 Coast Down Time Lockout
6 Phase Loss Trip 19 Starts Per Hour Lockout
7 Shunt Trip 20 Time Between Starts Lockout
8 OL (Motor Thermal Overload) Trip 21 Any Lockout (#18-#20)
9 OT (Starter Thermal Over Temperature) Trip 22 Run Timer (F030) Engaged
10 Short Circuit Trip 23 Run / Stop with On-delay from F063
11 Current Imbalance Trip 24 At-Speed / Stop with On-delay from F063
12 Over Current (Shear-Pin) Trip 25 At-Speed / End of Decel w/ On-delay from F063
13 Under Current Trip 26 Start / End of Decel with On-delay from F063
27
Power Loss (nCP No Control Power) Trip
Table 7: Aux. Relay Settings
*Note: Flash rate for Setting #17 is ½ second On and Off

