Toshiba TOSVERT VF-AS1 Option Instruction Manual

E6581279
-13‑
5. Communications-related parameters of the VF-AS1
On the network, the VF-AS1 (including the PDP002Z) serves as a slave device. Using the
parameters listed below, set the slave device on the network and its mode of operation.
The GSD files used to configure the PDP002Z can be downloaded from the Toshiba
Schneider Inverter web site.
http://www.inverter.co.jp/product/inv/vfas1/pdp/
Parameter Function Adjustment range Default setting
f830* Communication option
setting 1
(PPO TYPE)
0: None
1: PPO TYPE 1
2: PPO TYPE 2
3: PPO TYPE 3
4: PPO TYPE 4
0
f851
Inverter operation
at
the
communications
loss action
(Network wire breaks)
0: Stop and break of connection
1: None
2: Deceleration stop
3: Coast stop
4: Emergency stop
5: Preset speed operation command
(Operating at the preset speed operation frequency
set with f852)
0
f852 Preset speed
operation selection
0: None
1 to 15: Preset speed
0
f853 Monitoring of
communication device
station address
Displays the station address assigned with the
DIP switch.
0 to 125
1
f854** Monitoring of
communications
device’s baud rate
Displays the network communication speed set
with the DIP switch.
0: 12 Mbit/s
1: 6 Mbit/s
2: 3 Mbit/s
3: 1.5 Mbit/s
4: 500 kbit/s
5: 187.5 kbit/s
6: 93.75 kbit/s
7: 45.45 kbit/s
8: 19.2 kbit/s
9: 9.6 kbit/s
255: Disabled
0
* When the parameters are changed, the power must be cycled to the VF-AS1 for the
changes to take effect.
** The baud rate of the PDP002Z is automatically set by configuration a baud rate for the
master.
