-6‑
1. Overview
The PDP002Z option allows the VF-AS1 inverter to be connected as a slave (DP-V0) into a
PROFIBUS network. Up to 126 stations* can be connected to the network (* including a
master. If no repeater is provided, up to 32 stations can be connected to each segment).
Master
(PLC, etc.)
VF-AS1 VF-AS1
VF-AS1
PROFIBUS
Maximum connectable units: 126
(In a case like the one above, PLC is
included in the count.)
PDP002Z PDP002Z
PDP002Z
Repeater
