E6581913
60
Status information 2 (FD42, FE42)
Status information 2 (current status): “Communication Number FD42”
Status information 2 (status immediately before the occurrence of a trip): “Communication No. FE42”
Bit Function 0 1 Remarks
0 (Undefined) - -
1 (Undefined) - -
2 (Undefined) - -
3 (Undefined) - -
4 (Undefined) - -
5 (Undefined) - -
6 (Undefined) - -
7 Maximum deceleration forced
stop
Normal Operation
8 Acceleration/deceleration pat-
tern selection1
9 Acceleration/deceleration pat-
tern selection2
00:Acceleration/deceleration 1
01:Acceleration/deceleration 2
10:Acceleration/deceleration 3
AD1 :
acc, dec
AD2 :
f500, f501
AD3 :f510, f511
10 (Undefined) - -
11 (Undefined) - -
12 OC stall level OC stall 1 OC stall 2
OC stall 1 :
f601
OC stall 2 :
f185
13 (Undefined) - -
14 (Undefined) - -
15 (Undefined) - -
Note: The bit described “Undefined” is unstable. Don’t use the bit for the judgment.
Status information 3 (FD49, FE49)
Status information 3 (current status): “Communication Number FD49”
Status information 3 (status immediately before the occurrence of a trip): “Communication No. FE49”
Bit Function 0 1 Remarks
0 RY terminal output hold OFF ON
1 OUT terminal output hold OFF ON
2 to 9 (Undefined) - -
10 Running (const) OFF ON
11 Healthy signal OFF ON This bit repeats On/off
every second.
12 Acceleration/deceleration
completion (RCH)
OFF ON Related parameters
f102
13 Specified speed reach (RCHF) OFF ON Related parameters
f101, f102
14 Running (Acceleration) OFF ON
15 Running (deceleration) OFF ON
Note: The bit described “Undefined” is unstable. Don’t use the bit for the judgment.
