Status information 1 (FD01, FE01)
Status information 1 (current status): “Communication Number FD01”
Status information 1 (status immediately before the occurrence of a trip): “Communication No. FE01”
Bit Specifications 0 1 Remarks
0 Failure FL No output Output in progress
1 Failure Not tripped Tripped Trip statuses include rtry
and trip retention status.
2 Alarm No alarm Alarm issued
3 Under voltage() Normal Under voltage
4 Motor section (1 or 2)
(THR 2 selection)
Motor 1 (THR 1) Motor 2 (THR 2) THR1 : pt=setting value,
vl, vlv, vb, thr
THR2 :
pt=0, f170,
f171, f172, f173
5 PID control OFF PID control
permitted
PID control
prohibited
6 Acceleration/deceleration
pattern selection (1 or 2)
Acceleration/
deceleration
pattern 1 (AD 1)
Acceleration/
deceleration pat-
tern 2 (AD 2)
AD1 :
acc, dec
AD2 :
f500, f501
7 DC braking OFF Forced DC braking
8 Jog run OFF Jog run
9 Forward/reverse run Forward run Reverse run
10 Run/stop Stop Run
11 Coast stop (ST=OFF) ST=ON ST=OFF
12 Emergency stop Not emergency
stop status
Emergency stop
status
13 Standby ST=ON Start-up process Standby Standby: Initialization completed,
not failure stop status, not alarm
stop status (MOFF, LL forced
stop), ST=ON, and RUN=ON
14 Standby Start-up process Standby Standby: Initialization completed,
not failure stop status, and not
alarm stop status (MOFF, LL
forced stop )
15 (Undefined) - -
Note: The bit described “Undefined” is unstable. Don’t use the bit for the judgment.
