E6581913
58
Output terminal block status (FD07, FE07)
Output terminal block status (current status): “Communication Number FD07”
Output terminal block status (status immediately before the occurrence of a trip): “Communication
Number FE07”
Using terminal function selection parameters, functions can be assigned individually to the terminals
on the output terminal block.
When using a terminal as a monitoring terminal, check beforehand the function assigned to each
terminal.
Data composition of output terminal block status (FD07, FE07)
Bit Terminal name Function (parameter title) 0 1
0 RY-RC Output terminal function selection 1 (f130)
1 OUT Output terminal function selection 2 (f131)
2 FL Output terminal function selection 3 (f132)
OFF ON
3 to 15 (Undefined) -
- -
Note: The bit described “Undefined” is unstable. Don’t use the bit for the judgment.
Example: Data set for FE07 when both the RY and FL terminals are ON = 0005H
0 0 0 0000000000101
FE07:
0
500
bit0 BIT15
Monitoring of the analog input with the computer (FE35,FE36,FE37)
Terminal VIA monitor (current status): “Communication Number FE35” (unit: 0.01%)
Terminal VIB monitor
(current status): “Communication Number FE36” (unit: 0.01%)
Terminal VIC monitor
(current status): “Communication Number FE37” (unit: 0.01%)
These monitors can also be used as A/D converters irrespective of the inverter’s control.
Terminal VIA and Terminal VIC monitor are capable of reading the data from external devices in a
range of 0.01 to 100.00% (unsigned data: 0H to 2710H).
Terminal VIB monitor is capable of reading the data from external devices in a range of -100.00 to
100.00% (signed data: D8F0H to 2710H).
If analog input mode is selected with the frequency setting mode selection parameter, however,
keep in mind that any data entered via an analog terminal is regarded as a frequency command.
