TOSIBOX
®
LOCK 150
Ports
• 1x USB 2.0, type A, 500 mA maximum load allowed
• 1 x RJ-45 WAN conn., 10/100 Mb/s, auto-negotiation (MDI / MDI-X)
• 3 x RJ-45 LAN conn., 10/100 Mb/s, auto-negotiation (MDI / MDI-X)
• 1 x RJ-45 Service conn., 10/100 Mb/s, auto-negotiation (MDI / MDI-X)
WAN connection features
• Independent of operating systems
• Works in all Internet connections (operator independent)
• Firewall friendly
• Works with dynamic, static and private IP addresses
• Built-in firewall, NAT
• Up to 10 concurrent VPN connections
• VPN throughput up to 10 Mb/s (BF-CBC 128 bit)
Physical properties
• 132 mm x 99 mm x 35.5 mm / 5.2” x 3.9”x 1.4” (L x W x H)
• Weight 365 g / 1.31 lbs (net weight article)
• Operating temperature: -20 °C … +55 °C / -4 °F … 131 °F
• Oparating humidity 20 - 80% RH, non condensing
• Storage temperature -40 °C … +70 °C / -40 °F … 158 °F
• Cast aluminium casing
• IP protection class: IP20
• Maximum operating altitude 2000 m / 6562 ft
• Overvoltage category I
USB modem options
• TB4GM2EU, TB4GM2AU
WLAN
• IEEE 802.11 b/g/n, max. 150 Mbps
• WEP, WPA-PSK, WPA2-PSK, WPA-PSK/WPA2-PSK Mixed, WPA-EAP, WPA2-EAP
TKIP/AES encryption
• Frequency 2.412 – 2.462 GHz, 11 channels
• Output power 18 dBm max
Powering requirements
• 10-30 V DC +/- 10% (absolute value), 7.2W max, reverse polarity protected
TOSIBOX
®
LOCK 150 POWER SOURCE
• Model ATS024T-W240V
• Operating temperature: 0 °C … +70 °C / 32°F… 158 °F @ 375mA / 9W load
• Operating humidity: 20 - 80% non-condensing
• Storage temperature: -20 °C … +70 °C / -4°F… 158 °F
• Storage humidity: 10 - 90% non-condensing
