56
TOSIBOX
®
LOCK 200
Ports
• 1x USB 2.0, type A, 500 mA maximum load allowed
• 1 x RJ-45 WAN conn., 10/100 Mb/s, auto-negotiation (MDI / MDI-X)
• 3 x RJ-45 LAN conn., 10/100 Mb/s, auto-negotiation (MDI / MDI-X)
• 1 x RJ-45 Service conn., 10/100 Mb/s, auto-negotiation (MDI / MDI-X)
WAN connection features
• Independent of operating systems
• Works in all Internet connections (operator independent)
• Firewall friendly
• Works with dynamic, static and private IP addresses
• Built-in firewall, NAT
• Up to 50 concurrent VPN connections
• VPN throughput up to 15 Mb/s (BF-CBC 128 bit)
Physical properties
• 140 mm x 36 mm x 125 mm / 5.51” x 1.42” x 4.92” (L x W x H)
• Weight 530 g / 1.17 lbs
• Operating temperature --20 °C … +50 °C / -4 °F … +122 °F
• Operating humidity 20 – 80% RH, non condensing
• Storage temperature -40 °C … +70 °C / -40 °F … +158 °F
• Cast aluminium casing
• IP protection class: IP20
• Maximum operating altitude 2000 m / 6562 ft
• Overvoltage category I
USB modem options
• TB4GM2EU, TB4GM2AU, for 3rd party options, please see:
http://www.tosibox.com/support
Powering requirements
• 8-27V DC +/-10%, 7.0W max, reverse polarity protected
