Toslon XR310 - Connection of BCS Box

Connection of BCS Box
CH8
Connect to
antenna
Socket to
GPS receiver
Connect to components of boats
like swithch, servo, etc
Power in
( DC12V@200mA
Socket: DC3.5/1.35)
CH7
CH6
CH5
CH4
CH3
CH2
CH1
+
-
7
