10
2. Stick Gasket and Sponge
● After the mounting hole area is properly prepared, open the package and remove
the carton and shipping pads from around the rooftop air conditioner.
● Carefully lift the outdoor unit with the package on top of the vehicle. Do not use
the outer plastic shroud for lifting. Do not lift by the air outlet grille at the back of
the outer case (see Figure 2).
● Take out 1 gasket and 1 sponge (sealing strip).
● Clean up any debris at the sticking position of the chassis (as shown in Figure 3)
on the outdoor unit to ensure that the sticking position is clean.
Figure 2
Figure 3
Sticking Position of Gasket
Sticking Position
of Sponge (Sealing Strip)
To Next Page
