100
Installation and Maintenance
Service Manual
Above data is subject to change without notice.
NO.
Description
Part Code
Qty
TW09HQ1C8D/I
Product Code CB456N00400_L59684
1 Front Panel 27230007569 1
2 Display Board 30565281 1
3 Front Case Assy 00000200040 1
4 Helicoid Tongue 26112508 1
5 Left Axile Bush 10512037 1
6 Rear Case assy 00000100066 1
7 Drainage Hose 0523001408 1
8 Ring of Bearing 26152022 1
9 O-Gasket sub-assy of Bearing 7651205102 1
10 Evaporator Support 24212180 1
11 Cold Plasma Generator / 0
12 Evaporator Assy 0100200004407 1
13 Wall Mounting Frame 01252043 1
14 Cross Flow Fan 10352059 1
15 Fan Motor 1501208905 1
16 Connecting pipe clamp 2611216401 1
17 Rubber Plug (Water Tray) 76712012 1
18 Stepping Motor 1521212901 1
19 Crank 73012005 1
20 Electric Box Assy 10000203235 1
21 Axile Bush 10542036 1
22 Terminal Board 42011233 1
23 Jumper 4202021911 1
24 Main Board 30138000659 1
25 Electric Box Cover Sub-Assy 0140206501 1
26 Shield Cover of Electric Box Cover 01592150 1
27 Electric Box Cover 2011220701 1
28 Power Cord / 0
29 Connecting Cable / 0
30 Connecting Cable / 0
31 Remote Controller 30510475_TOSOT 1
To Next Page
